Industrial Automation Products

FESTO • RKD1820860

MS4N-FRM-1/4-Y
BRANCHING MODULE
0-12 BAR OPERATING PRESSURE
4600 L/MIN STANDARD NOMINAL FLOW RATE
(4) 1/4 NPT CONNECTIONS
531953

FESTO • RKD1623488

MS4N-LDM1-1/4-P10
MEMBRANE AIR DRYER
MS4N SERIES
3-12.5 BAR OPERATING PRESSURE
100 L/MIN FLOW RATE
(2) 1/4 NPT CONNECTIONS
543636

FESTO • RKD1820862

MS4N-LF-1/4-CRV
COMPRESSED AIR FILTER
MS4N SERIES
5 MICROMETERS OF FILTRATION
FULLY AUTO DRAIN
19ML MAX CONDENSATE VOLUME
2-12 BAR OPERATING PRESSURE
1300 L/MIN FLOW RATE
(2) NPT1/4-18 CONNECTION
531493

FESTO • RKD1809030

MS4N-LF-1/4-ERM
COMPRESSED AIR FILTER
MS4N SERIES
40 MICROMETERS OF FILTRATION
MANUALLY ROTATING DRAIN
19ML MAX CONDENSATE VOLUME
0-14 BAR OPERATING PRESSURE
1700 L/MIN FLOW RATE
(2) NPT1/4-18 CONNECTIONS
531485

FESTO • RKD1800237

MS4N-LFM-1/4-ARM
MICRO FILTER
MS4N SERIES
0.01 MICROMETERS OF FILTRATION
MANUALLY ROTATING DRAIN
0-14 BAR OPERATING PRESSURE
360 L/MIN MAX FLOW RATE
100% FILTER EFFICIENCY
19ML MAX CONDENSATE VOLUME
(2) 1/4 NPT CONNECTIONS
531812

FESTO • RKD1809032

MS4N-LFR-1/4-D6-CRM-AS
FILTER REGULATOR
MS4N SERIES
5 MICROMETERS FILTRATION
MANUALLY ROTATING DRAIN
WITH PRESSURE GAUGE
19ML MAX CONDENSATE VOLUME
0.8-14 BAR OPERATING PRESSURE
0.3-7 BAR PRESSURE REGULATION RANGE
1500 L/MIN FLOW RATE
(2) NPT1/4-18 CONNECTIONS
531229

FESTO • RKD1623490

MS4N-LFR-1/4-D6-CRV-AS
FILTER REGULATOR
MS4N SERIES
5 MICROMETERS FILTRATION
AUTO CONDENSATE DRAIN
WITH PRESSURE GAUGE
19 ML MAX CONDENSATE VOLUME
2-12 BAR OPERATING PRESSURE
0.3-7 BAR PRESSURE REGULATION RANGE
1500 L/MIN FLOW RATE
NPT1/4-18 CONNECTION
531233

FESTO • RKD1820866

MS4N-LFR-1/4-D6-ERM-AS
FILTER REGULATOR
MS4N SERIES
ROTARY KNOB WITH DETENT ACTUATOR LOCK
40 MICROMETER FILTRATION
WITH PRESSURE GAUGE
19 ML MAX CONDENSATE VOLUME
0.8-14 BAR OPERATING PRESSURE
0.3-7 BAR PRESSURE REGULATION RANGE
1700 L/MIN STANDARD NOMINAL FLOW
531221

FESTO • RKD1820869

MS4N-LFR-1/4-D7-C-U-V-AD1-AS
DISCONTINUED BY MANUFACTURER
FILTER REGULATOR
ACTUATOR LOCK: DIGITAL
5 MICROMETERS OF FILTRATION
CONDENSATE VOLUME: 25 ML
OPERATING PRESSURE: 2 BAR-12 BAR
1200 L/MIN
NPT1/4-18 (X2)
527694

FESTO • RKD1759730

MS4N-LFR-1/4-D7-CRM-AS
FILTER REGULATOR
MS4N SERIES
5 MICROMETERS FILTRATION
MANUALLY ROTATING DRAIN
WITH PRESSURE GAUGE
19ML MAX CONDENSATE VOLUME
0.8-14 BAR OPERATING PRESSURE
0.5-12 BAR PRESSURE REGULATION RANGE
1200 L/MIN FLOW RATE
(2) NPT1/4-18 CONNECTIONS
531213

FESTO • RKD1789980

MS4N-LFR-1/4-D7-CRV-AS
FILTER REGULATOR
MS4N SERIES
5 MICROMETERS OF FILTRATION
FULLY AUTO DRAIN
WITH PRESSURE GAUGE
19ML MAX CONDENSATE VOLUME
2-12 BAR OPERATING PRESSURE
0.5-12 BAR PRESSURE REGULATION RANGE
1200 L/MIN FLOW RATE
(2) NPT1/4-18
531217

FESTO • RKD1701649

MS4N-LFR-1/4-D7-ERM-AS
FILTER REGULATOR
40 MICROMETERS OF FILTRATION
MANUALLY ROTATING DRAIN
WITH PRESSURE GAUGE
19ML MAX CONDENSATE VOLUME
0.8-14 BAR OPERATING PRESSURE
0.5-12 BAR PRESSURE REGULATION RANGE
1500 L/MIN FLOW RATE
(2) NPT1/4-18 CONNECTIONS
531205

FESTO • RKD1789983

MS4N-LOE-1/4-R
AIR LINE LUBRICATOR
SERIES MS
SIZE 4
30 CM3 MAX. OIL
1-12 BAR OPERATING PRESSURE
2200 L/MIN FLOW RATE
1/4 NPT PNEUMATIC CONNECTIONS
PLASTIC BOWL GUARD
DIE-CAST ALUMINUM HOUSING
(531702)

FESTO • RKD1623493

MS4N-LR-1/4-D5-AS
PRESSURE REGULATOR
MS4N SERIES
ROTARY KNOB WITH DETENT ACTUATOR LOCK
WITH PRESSURE GAUGE
0.8-14 BAR OPERATING PRESSURE
0.3-4 BAR PRESSURE REGULATION RANGE
2100 L/MIN STANDARD NOMINAL FLOW RATE
NPT1/4-18 PNUEMATIC CONNECTIONS
531418

FESTO • RKD1809035

MS4N-LR-1/4-D6-AS
PRESSURE REGULATOR
SERIES MS
SIZE 4
ROTARY KNOB WITH DETENT
0.8-14 BAR OPERATING PRESSURE
1800 L/MIN FLOW RATE
1/4 NPT PNEUMATIC CONNECTIONS
DIE-CAST ALUMINUM HOUSING
(531422)

FESTO • RKD1759733

MS4N-LR-1/4-D7-AS
PRESSURE REGULATOR
MS4N SERIES
DIRECTLY CONTROLLED DIAPHRAGM REGULATOR
WITH PRESSURE GAUGE
0.8-14 BAR OPERATING PRESSURE
0.5-12 BAR PRESSURE REGULATION RANGE
1700 L/MIN FLOW RATE
(2) NPT1/4-18 CONNECTIONS
531426

FESTO • RKD1701654

MS4N-LR-1/8-D5-AS
PRESSURE REGULATOR
MS4N SERIES
DIRECTLY CONTROLLED DIAPHRAGM REGULATOR
WITH PRESSURE GAUGE
0.8-14 BAR OPERATING PRESSURE
0.3-4 BAR PRESSURE REGULATION RANGE
1200 L/MIN FLOW RATE
(2) NPT1/8-27
531419

FESTO • RKD1789985

MS4N-LRB-1/4-D5-AS
PRESSURE REGULATOR
MS4N SERIES
ROTARY KNOB WITH DETENT ACTUATOR LOCK
WITH PRESSURE GAUGE
0.8-14 BAR OPERATING PRESSURE
0.3-4 BAR PRESSURE REGULATION RANGE
1900 L/MIN FLOW RATE
1/4 NPT PNEUMATIC CONNECTION
531780

FESTO • RKD1820872

MS4N-LRB-1/4-D6-A8-AS
PRESSURE REGULATOR
MS4N SERIES
DIRECTLY CONTROLLED DIAPHRAGM REGULATOR
G1/8 PREPARED PRESSURE GAUGE
0.8-14 BAR OPERATING PRESSURE
0.3-7 BAR PRESSURE REGULATION RANGE
1700 L/MIN FLOW RATE
(2) 1/4 NPT CONNECTIONS
531793

FESTO • RKD1789988

MS4N-LRB-1/4-D7-AS
PRESSURE REGULATOR
MS4N SERIES
DIRECTLY CONTROLLED DIAPHRAGM REGULATOR
WITH PRESSURE GAUGE
0.8-14 BAR OPERATING PRESSURE
0.5-12 BAR PRESSURE REGULATION RANGE
1500 L/MIN FLOW RATE
(2) 1/4 NPT CONNECTIONS
531784

FESTO • RKD1623500

MS6-A-RMV-IPM-80
BRANCHING MODULE
MOUNTING COMPONENT
MS6 SIZE
DIE-CAST ALUMINUM MATERIAL
STEEL SCREWS
NBR SEALS

FESTO • RKD1800245

MS6-AD
DISCONTINUED BY MANUFACTURER
ADAPTER MODULE
PNEUMATIC APPLICATION

FESTO • RKD1623498

MS6-AEND
MOUNTING PLATE
-20 TO 75 DEG C
3.11 WIDTH
(535408)

FESTO • RKD1537106

MS6-AEND1
MOUNTING PLATE
SERIES MS
SIZE 6
DIRECT THREAD IN PROTECTION
WPB WALL ANGLES
POM / STEEL
CORROSION RESISTANCE CLASS - 2
